Safe hot runner systems from HEITEC for medical technology
Wherever plastic products are needed to help protect people's health, we provide support with our hot runner systems. The manufacturing of syringe barrels, pipettes, test vessels, catheters and cuvettes places extreme demands on process reliability, reproducibility and manufacturing efficiency. We consider the creation of hot runner systems for the medtech industry one of our core competencies – let’s talk about future-proof hot runner systems for your projects.
Special requirements in medical technology
- Parts with edge gates
- Close cavity spacing
- Clean-room manufacturing
- Perfect gate marks
- Short cycle times
- Multi-cavity moulds
Our solutions for the medtech industry:
Application examples
Medical equipment
DISPOSABLE CATHETER
| Technical data | |
|---|---|
| Item weight: | 0,9 g |
| Material: | PA 6 |
| Dimensions: | 6,2 x 30 mm |
| Cavities: | 4-fold |
| Nozzle type: | 01.058.17.60 |
| Feature: | Tube overmoulding |
Heitec products:
X-PURE-LINE
Medical equipment
NEEDLE SAFETY COVER
| Technical data | |
|---|---|
| Item weight: | 1,1 g/piece |
| Material: | PP |
| Dimensions: | 8,1 x 8,1 x 60, 5 mm |
| Cavities: | 16-fold |
| Nozzle type: | 01.78.44 |
Heitec products:
STAR-LINE
Medical equipment
CUVETTE, 9-FOLD
| Technical data | |
|---|---|
| Item weight: | 3,8 g/piece |
| Material: | PMMA |
| Dimensions: | 19,6 x 33,4 mm |
| Cavities: | 9 x 4-fold |
| Nozzle type: | 01.041.06 |
| Special feature: | 7mm cavity spacing |
Heitec products:
FLAT-LINE
Medical equipment
LUER LOCK ADAPTER
| Technical data | |
|---|---|
| Item weight: | 0,9 g |
| Material: | ABS |
| Dimensions: | Ø 11 x 33 mm |
| Cavities: | 16-fold |
| Nozzle type: | 01.01.15.50 |
| Special features: | Edge gating, individually controlled |
Heitec products:
FIRST-LINE
HORIZONTAL MANIFOLD
Medical equipment
SYRINGE PLUNGER - 5 ML
| Technical data | |
|---|---|
| Item weight: | 1,6 g |
| Material: | PP |
| Dimensions: | Ø 12 x 75 mm |
| Cavities: | 48 |
| Nozzle type: | 01.78.44 |
| Special feature: | Edge gating |
Heitec products:
STAR-LINE
Medical equipment
SYRINGE BARREL - 5 ML
| Technical data | |
|---|---|
| Item weight: | 2,6 g |
| Material: | PP |
| Dimensions: | Ø 12 x 75 mm |
| Cavities: | 48 |
| Nozzle type: | 01.078.44 |
| Special feature | Edge gating |
Heitec products:
STAR-LINE
