Hot runner nozzleSINGLE-STAR-LINE-CROWN LINEAR 2-FACH

Typ 01.276.44.02.

Product types

Type	L	D	d2	d3	d4	d5	a	b	h	h1	h2	Y	z
01.276.44.02.100	100	28	44	32	6	26	21,5	17	24	33	60	38,5	10
01.276.44.02.120	120	28	44	32	6	26	21,5	17	24	33	60	38,5	10
01.276.44.02.160	160	28	44	32	6	26	21,5	17	24	33	60	38,5	10
01.276.44.02.200	200	28	44	32	6	26	21,5	17	24	33	60	38,5	10
01.276.64.02.120	120	43	64	46	9	38	24,5	25	30	39	66	50	13,3
01.276.64.02.160	160	43	64	46	9	38	24,5	25	30	39	66	50	13,3
01.276.64.02.200	200	43	64	46	9	38	24,5	25	30	39	66	50	13,3
01.276.64.02.220	220	43	64	46	9	38	24,5	25	30	39	66	50	13,3

Download Data sheed and CAD data

Data sheet

CAD-file

Our product Configurator takes you to your perfect hot runner system

Use our Configurator to configure your custom hot runner product. You will immediately receive the necessary CAD data for your design process.
